| Auxiliary Interface |
Serial Interface : 1 RS-485 (full-duplex), 1 RS-232, 1 keyboard
SATA : 16 SATA interfaces supporting hot-plug
ESATA : 1 eSATA interface
Capacity : Up to 10TB capacity for each disk
Alarm In/Out : 16/8
USB Interface : Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Decoding |
Decoding Format : H.265/H.265+/H.264/H.264+/MPEG4
Recording Resolution : 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
For DS-9632NI-I16, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24-ch.
Synchronous Playback : 16-ch
Decoding Capability : 1-ch@32 MP (30 fps)/2-ch@12 MP (20fps)/4-ch@8 MP (25fps)/8-ch@4 MP (30fps)/16-ch@1080p (30fps)
Dual-Stream Recording : Support
Stream Type : Video, Video & Audio
Audio Compression : G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
| Network |
Remote Connection : 128
Network Protocol : TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface : 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Video and Audio |
IP Video Input : 64-ch
Up to 12 MP resolution
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
For DS-9632NI-I16, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24-ch.
Incoming Bandwidth : 320 Mbps Outgoing Bandwidth : 256 Mbps Incoming Bandwidth (RAID Mode) : 200 Mbps Outgoing Bandwidth (RAID Mode) : 200 Mbps HDMI 1 Output : 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI 2 Output : 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA 1 Output : 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA 2 Output : 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode : HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output
CVBS Output : 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480V Audio Input : 1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output : 2-ch, RCA (Linear, 1 KΩ)
Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 k Ω)
|
