| AUDIO AND VIDEO |
| IP Camera Input |
Up to 64-ch 12 MP IP cameras can be connected |
| Two-Way Talk |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| DISPLAY |
| Interface |
H.265+/H.265/H.264/H.264+/MPEG4 |
| Decoding Capacity |
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps) |
| RECORDING |
| Resolution |
CVBS output (Optional) : 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 VGA1 /HDMI1 output resolution : HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × VGA2 /HDMI2 output resolution : 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Record Rate |
128 Mbps |
| VIDEO DETECTION AND ALARM |
| Alarm Input |
Yes |
| PLAYBACK AND BACKUP |
| Sync Playback |
Yes ( 8-ch ) |
| Playback Function |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF |
| THIRD PARTY SUPPORT |
| Third Party Support |
YesH.265+/H.265/H.264/H.264+/MPEG4 |
| NETWORK |
| Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Ethernet Port |
2 |
| Network Function |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
| STORAGE |
| HDD Mode |
8 SATA interfaces for 8HDDs Up to 10TB capacity for each HDD |
| eSATA |
1 eSATA interface |
| AUXILIARY INTERFACE |
| USB |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| RS232 |
Yes |
| RS485 |
Yes |
| POWER |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Power Consumption |
Max. Power : 200 W Consumption (without HDD) : ≤ 30 W |
| CONSTRUCTION |
| Dimensions |
445 × 470 ×90 mm (17.5"× 18.5" × 3.5") |
| Net Weight |
Weight (without HDD) : ≤ 8 kg (17.6 lb) |
HIKVISION DS-7216HUHI-K2 16-CH Turbo HD 1080P DVR
The HIKVISION DS-7216HUHI-K2 16-CH Turbo HD 1080P DVR is a cutting-edge digital video recorder designed to meet the demanding requirements of modern surveillance systems. With its advanced features and high-performance capabilities, this DVR stands out as a reliable and efficient solution for both commercial and residential security applications.
Featuring support for up to 16 channels, this DVR allows users to connect a variety of HD-TVI and analog cameras, providing flexibility in designing a comprehensive surveillance network. The inclusion of Turbo HD technology ensures that the system delivers crystal-clear 1080P resolution, capturing details with exceptional clarity. Whether monitoring a retail space, office, or home environment, the DS-7216HUHI-K2 offers the level of precision needed for effective surveillance. Equipped with HDMI and VGA outputs, the DVR enables users to view footage on high-definition monitors, enhancing the monitoring experience. The versatility of connectivity options ensures seamless integration with different display devices, allowing for a user-friendly and accessible interface. With two SATA interfaces, the DS-7216HUHI-K2 provides ample storage capacity for recorded footage. This is crucial for maintaining an extensive archive of video data, ensuring that users can review past events as needed. The DVR's robust storage capabilities make it suitable for continuous, around-the-clock monitoring in environments where security is of the utmost importance. The DS-7216HUHI-K2 also supports access through the EZVIZ Cloud P2P service, offering convenient remote access to the surveillance system. This feature allows users to monitor their premises from anywhere with an internet connection, providing real-time insights and control over the security of their property.
