| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video Bit Rate |
256Kbps~16Mbps |
| Triple Streams |
Yes |
| Max. Image Resolution |
2688 × 1520 |
| Frame Rate |
50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)<br>60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)<br>60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)<br>60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Image Enhancement |
BLC/3D DNR/ROI/HLC |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser |
| Target Cropping |
No |
| ROI |
1 fixed region for the main stream and sub-stream |
| Day/Night Switch |
Day/Night/Auto/Schedule |
| Network Storage |
Support micro SD/SDHC/SDXC card (128G), flash memory, ANR |
| Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, mask, Watermark, IP address filtering |
| System Compatibility |
ONVIF (Profile S, Profile G), ISAPI |
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
| On-board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button |
Yes |
| Behavior Analysis |
Line crossing detection, intrusion detection |
| Line Crossing Detection |
Cross a pre-defined virtual line |
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region |
| Recognition |
Face Detection |
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption |
-I5: 12 VDC, 0.6A, max. 7.5W; PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 9.5W<br>-I8: 12 VDC, 0.95A, max. 11.5W; PoE (802.3af, 37V to 57V), 0.35A to 0.1A, max. 12.5W |
| Weather Proof |
IP67 |
| IR Range |
-I5: up to 50 m; -I8: up to 80 m |
| Dimensions |
Camera: Φ 105 × 299.7 mm (Φ 4.1″ × 11.8″)<br>Package: 386 × 156 × 155 mm (15.2″ × 6.14″ × 6.1″) |
| Weight |
Camera: Approx. 1180 g (2.6 lb.)<br>With Package: Approx |
