| Basic Information | ||
| Supported CPU | 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors<br> 10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / <br>Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors | |
| Chipset | Intel Z590 Express Chipset | |
| BIOS | 1 x 256 Mbit flash<br> Use of licensed AMI UEFI BIOS<br> PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Form Factor | https://www.website.com.bd/gigabyte-z590-ud-ac-atx-<br>motherboard#:~:text=ATX%20Form%20Factor%3B%2030.5cm%20x%2024.4cm | |
| Audio | Realtek audio CODEC<br> High Definition Audio<br> 2/4/5.1/7.1-channel<br> Support for S/PDIF Out | |
| Memory Specifications | ||
| Type | Dual-channel memory architecture | |
| Slots | 4 x DDR4 DIMM | |
| Supported Memory | 11th Generation Intel Core i9/i7/i5 processors:<br> Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ <br>4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / <br>4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / <br>3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz<br> 10th Generation Intel Core i9/i7 processors:<br> Support for DDR4 2933/2666/2400/2133 MHz memory modules<br> 10th Generation Intel Core i5/i3/Pentium/Celeron processors:<br> Support for DDR4 2666/2400/2133 MHz memory modules<br> 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory<br> Dual-channel memory architecture<br> Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)<br> Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules<br> Support for Extreme Memory Profile (XMP) memory modules | |
| Max. Memory | 128 GB (32 GB single DIMM capacity) | |
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16 (PCIEX16)<br> * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to<br> install it in the PCIEX16 slot.<br> (The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)<br> 1 x PCI Express x16 slot, running at x4 (PCIEX4)<br> 2 x PCI Express x1 slots<br> (The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.) | |
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4 SSD support) (M2P_CPU) (Note)<br> Chipset:<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD <br>support) (M2A_SB)<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) (M2M_SB) | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support:<br> 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz<br> * Support for DisplayPort 1.2 version and HDCP 2.3<br> Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies | |
| Connector & Ports | ||
| USB (s) | Chipset:<br> 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel<br> 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)<br> 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header<br> Chipset+2 USB 2.0 Hubs:<br> 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) | |
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) | |
| Supported Storage | CPU:<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4 SSD support) (M2P_CPU) (Note)<br> Chipset:<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD <br>support) (M2A_SB)<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) <br>(M2M_SB) 5 x SATA 6Gb/s connectors<br> Support for RAID 0, RAID 1, RAID 5, and RAID 10<br> * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.<br> Intel Optane Memory Ready | |
| Audio | 3 x audio jacks | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector<br> 1 x 8-pin ATX 12V power connector<br> 1 x 4-pin ATX 12V power connector<br> 1 x CPU fan header<br> 4 x system fan headers<br> 2 x addressable LED strip headers<br> 2 x RGB LED strip headers<br> 1 x Q-Flash Plus button<br> 5 x SATA 6Gb/s connectors<br> 3 x M.2 Socket 3 connectors<br> 1 x front panel header<br> 1 x front panel audio header<br> 1 x S/PDIF Out header<br> 1 x USB 3.2 Gen 1 header<br> 1 x USB Type-C header, with USB 3.2 Gen 1 support<br> 2 x USB 2.0/1.1 headers<br> 2 x Thunderbolt add-in card connectors<br> 1 x serial port header<br> 1 x Clear CMOS jumper | |
| Others Information | ||
| Special Features | Support for APP Center<br> @BIOS<br> EasyTune<br> Fast Boot<br> Game Boost<br> ON/OFF Charge<br> RGB Fusion<br> Smart Backup<br> System Information Viewer<br> Support for Q-Flash Plus<br> Support for Q-Flash<br> Support for Xpress Install | |
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
The Gigabyte Z590 UD AC Motherboard uses an 12+1 phase digital CPU power design which includes both a digital PWM Controller and Dr MOS. These 100% digital controllers and additional 8+4 Solid-pin CPU Power Connectors offer cleaner and more efficient power delivery to the CPU with greater thermal performance ensuring stability under high frequencies and heavy loads.
Gigabyte Z590 UD AC Motherboard is offering a tested and proven platform that ensures proper compatibility with profiles up to 5000MHz and beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable and that the XMP function is activated and enabled on their GAMING motherboard.
In order to get the highest possible performance from the latest high-core Intel processors, a comprehensive cooling solution is needed. The Gigabyte Z590 UD AC Motherboard uses an Advanced Thermal Design with Integrated IO Armor thick thermal pads to increase overall heat dissipation and maximise thermal efficiency whilst still maintaining a stylish aesthetic, this also includes Smart Fan 6 technology which includes several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.
The latest price of Gigabyte Z590 UD AC Intel 10th and 11th Gen ATX Motherboard in Bangladesh is 21,800৳ You can buy the Gigabyte Z590 UD AC Intel 10th and 11th Gen ATX Motherboard at best price from our Website or visit any of our showrooms.
