| Basic Information | ||
| Supported CPU | AMD Socket AM5, support for:<br> AMD Ryzen 9000 Series Processors/<br> AMD Ryzen 8000 Series Processors/<br> AMD Ryzen 7000 Series Processors | |
| Chipset | AMD X870 | |
| Operating System | Support for Windows 11 64-bit | |
| Physical Specification | ||
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm | |
| Motherboard | ||
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS<br> PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Memory | Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules.<br> 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory<br> Dual channel memory architecture<br> Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules <br> Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules | |
| Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:<br> AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode<br> AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode<br> AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode<br Chipset:<br> - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)<br> | |
| Supported Storage | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:<br> AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs<br> AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs<br> AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs<br> 2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:<br> AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs<br> * The M2B_CPU and M2C_CPU connectors become unavailable when an AMD Ryzen 8000 Series-Phoenix 1/Phoenix 2 processor is used.<br> 1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs<br> 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices<br> * RAID 5 is only available on AMD Ryzen 9000 Series Processors.<br> RAID 0, RAID 1, and RAID 10 support for SATA storage devices<br> | |
| Others | ||
| Software | H/W Monitoring:<br> Support for GIGABYTE Control Center (GCC)<br> Support for Q-Flash<br> Support for Q-Flash Plus<br> Support for Smart Backup<br> Bundled Software:<br> Norton Internet Security (OEM version)<br> iTE I/O Controller Chip<br> | |
| Graphics | ||
| Graphics | ntegrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4 Controller:<br> - 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz * Support for DisplayPort 1.4 version and HDR.<br> Integrated Graphics Processor with AMD Radeon Graphics support:<br> - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz<br> * Support for HDMI 2.1 version, HDCP 2.3, and HDR.<br> ** Support for native HDMI 2.1 TMDS compatible ports.<br> - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz | |
| Connectivity | ||
| HDMI | 1 x HDMI port | |
| USB Port(s) | CPU+ASMedia USB4 controller:<br> - 2 x USB4 USB Type-C ports on the back panel<br> CPU+USB 3.2 Gen 1 Hub:<br> 4 x USB 3.2 Gen 1 ports on the back panel<br> CPU+USB 2.0 Hub:<br> - 4 x USB 2.0/1.1 ports on the back panel<br> Chipset:<br> - 1 x USB Type-C port with USB 3.2 Gen 2x2 support, available through<br> the internal USB header<br> - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel<br> - 2 x USB 3.2 Gen 1 ports available through the internal USB header<br> - 4 x USB 2.0/1.1 ports available through the internal USB headers | |
| Wi-Fi | Realtek Wi-Fi 7 RTL8922AE<br> - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands | |
| Connector & Ports | ||
| Audio | Realtek ALC1220 CODEC<br> High Definition Audio<br> 2/4/5.1/7.1-channel Support for S/PDIF Out | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector<br> 2 x 8-pin ATX 12V power connectors<br> 1 x CPU fan header<br> 1 x CPU fan/water cooling pump header<br> 4 x system fan headers<br> 2 x system fan/water cooling pump headers<br> 1 x RGB LED strip header<br> 4 x M.2 Socket 3 connectors<br> 4 x SATA 6Gb/s connectors<br> 1 x front panel header<br> 1 x front panel audio header<br> 1 x USB Type-C header, with USB 3.2 Gen 2x2 support<br> 1 x USB 3.2 Gen 1 header<br> 2 x USB 2.0/1.1 headers<br> 1 x noise detection header<br> 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)<br> 1 x HDMI port (Note)<br> 1 x power button<br> 1 x reset button<br> 2 x temperature sensor headers<br> 1 x reset jumper<br> 1 x Clear CMOS jumper<br> | |
| Network & Connectivity | ||
| LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | |
| Network & Wireless Connectivity | ||
| Bluetooth | - BLUETOOTH 5.4<br> - Support for 11be 160MHz wireless standard | |
| Others Information | ||
| Special Features | Support for GIGABYTE Control Center (GCC)<br> Support for Q-Flash<br> Support for Q-Flash Plus<br> Support Smart Backup | |
| Warranty Information | ||
| Warranty | 3-Years | |
The Gigabyte X870M A ELITE WF7 motherboard is a high-performance Micro ATX board designed for gamers, creators, and power users seeking cutting-edge technology and reliability. Built on the AMD X870 chipset and supporting the latest AMD Socket AM5 processors, it is compatible with Ryzen 9000, 8000, and 7000 Series CPUs, ensuring top-tier performance and future-ready capability For memory, the board offers four DDR5 DIMM slots, supporting up to 256 GB of ultra-fast RAM with speeds reaching 8200 MHz (O.C.). It supports both AMD EXPO and Intel XMP profiles, allowing easy memory overclocking and stability optimization. Storage expansion is extensive, featuring four M.2 connectors and four SATA 6Gb/s ports, with PCIe 5.0 x4 support for lightning-fast NVMe SSDs and RAID configurations up to RAID 5 on Ryzen 9000 processors. Graphics and display capabilities are enhanced by integrated AMD Radeon Graphics and ASMedia USB4 controllers, providing two USB4 Type-C ports with DisplayPort 1.4 and one HDMI 2.1 output, supporting resolutions up to 4K at 240Hz. Networking is handled by a Realtek 2.5GbE LAN chip and Wi-Fi 7 (RTL8922AE) module with Bluetooth 5.4, ensuring seamless high-speed connectivity and low latency. The board includes a PCIe 5.0 x16 slot for next-generation GPUs and an additional PCIe 4.0 x4 slot for expansion. Audio is powered by the Realtek ALC1220 codec, delivering rich 7.1-channel HD sound with S/PDIF Out. Convenient features such as Q-Flash Plus, Smart Backup, and GIGABYTE Control Center (GCC) enhance usability and system management. Designed with premium components and efficient thermal solutions, the Gigabyte X870M A ELITE WF7 offers exceptional performance, versatility, and durability — a perfect foundation for a modern, high-end PC build.
The latest price of Gigabyte X870M A ELITE WF7 Motherboard in Bangladesh is 39,200৳ You can buy the Gigabyte X870M A ELITE WF7 Motherboard at best price from our Website or visit any of our showrooms.
