GIGABYTE A520M K AMD AM4 ULTRA DURABLE MOTHERBOARD

Processor
Supported CPU	AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors
Mainboard
Chipset	AMD A520
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
Memory	2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Storage
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
Graphics
Graphics	1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB
Networking & Connectivity
LAN	Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Audio & Microphone
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
Ports
Slots	CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x speaker header 1 x Clear CMOS jumper 1 x chassis intrusion header
External I/O Ports	1 x PS/2 keyboard/mouse port 1 x HDMI port 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks
USB	CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
HDMI	1 x HDMI port
Software
Software Features	Norton® Internet Security (OEM version) LAN bandwidth management software
Special Features
Special Features	Support for APP Center @BIOS EasyTune Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install
Others
Other Features	I/O Controller: iTE® I/O Controller Chip H/W Monitoring: Voltage detection Temperature detection Fan speed detection Fan fail warning Fan speed control Operating System: Support for Windows 11 64-bit Support for Windows 10 64-bit
Physical Specification
Form Factor	Micro ATX Form Factor
Dimension	23.3cm x 19.8cm
Warranty Information
Warranty	03 Years Warranty

The GIGABYTE A520M K AMD AM4 Ultra Durable Motherboard delivers a perfect balance of performance, reliability, and essential connectivity for mainstream PC builders. Built on the AMD A520 chipset and designed for the AM4 socket, this board supports a wide range of AMD Ryzen processors, including Ryzen 3000, 4000G, and 5000 series CPUs. Its robust design and proven Ultra Durable technologies ensure long-lasting stability, making it ideal for home office rigs, everyday gaming systems, and multimedia computers. Constructed in a compact micro-ATX form factor, the A520M K maximizes functionality while fitting easily into smaller chassis. Users can install up to 64GB of DDR4 memory across two DIMM slots, with support for memory speeds up to 5100 MHz (OC)—providing ample headroom for multitasking applications, creative workloads, and gaming experiences. Whether you’re browsing, streaming, or running productivity software, this board’s memory support helps deliver smoother performance. For graphics output, the motherboard includes a full-featured HDMI port, allowing you to connect directly to modern displays and enjoy crisp visuals without the need for an add-in graphics card when paired with Ryzen processors that include integrated graphics. This board also offers a dedicated M.2 slot for high-speed NVMe SSDs, giving you accelerated load times and responsive system performance. Networking is powered by Realtek Gigabit Ethernet, ensuring a stable and dependable connection for online gaming, video conferencing, and downloads. The motherboard’s Ultra Durable components—such as high-quality PCB design and long-lasting capacitors—enhance durability and heat resistance, helping your system run cooler and more reliably over extended use. Overall, the GIGABYTE A520M K is an excellent choice for users seeking a capable, affordable foundation for building everyday AMD-powered PCs. Its combination of essential features, solid build quality, and wide processor support makes it a versatile and trustworthy platform for a variety of computing needs.
