| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
| Shutter Time |
1/3 s to 1/100,000 s |
| Slow Shutter |
Support |
| Lens |
2.8 mm, horizontal field of view: 108°
6 mm, horizontal field of view: 52°
8 mm, horizontal field of view: 41°
12 mm, horizontal field of view: 25°
|
| Lens Mount |
M12 |
| Adjustment Range |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Day & Night |
IR cut filter with auto switch |
| Wide Dynamic Range |
120 dB |
| Digital Noise Reduction |
3D DNR |
| Focus |
Fixed |
| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video Bit Rate |
32Kbps~16Mbps |
| Audio Compression |
-S: G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Triple Streams |
Yes |
| Max. Image Resolution |
1920 x 1080 |
| Frame Rate |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280×720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280×720)
|
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Third Stream |
50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240)
|
| Image Enhancement |
BLC/3D DNR/HLC |
| Image Settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| ROI |
Support 1 fixed region for main stream and sub stream separately |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In(-S) |
| Network Storage |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
| System Compatibility |
ONVIF (Profile S, Profile G), ISAPI |
| Audio |
With -S model: 1 audio input (line in), 1 audio output interface, terminal block |
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
| Alarm |
With -S model: 1 alarm input, 1 alarm output (max. 12 VDC, 30 mA), terminal block |
| On-board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button |
Yes |
| Environment Noise Filtering |
Support(-S) |
| Audio I/O |
Support |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz |
| Behavior Analysis |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Line Crossing Detection |
Cross a pre-defined virtual line |
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region |
| Unattended Baggage |
Objects left over in the pre-defined region such as baggage, purse, dangerous materials |
| Object Removal |
Objects removed from the pre-defined region, such as exhibits on display |
| Exception Detections |
Scene change detection |
| Recognition |
Face Detection |
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption |
12 VDC ± 25%, 5W |
| PoE(802.3af, class 3), 6.5W |
| Impact Protection |
IK10 |
| Weather Proof |
IP67 |
| IR Range |
Up to 30m |
| Dimensions |
Camera: Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″) |
| Package |
134 × 134 × 108 mm (5.27″ × 5.27″ × 4.25″) |
| Weight |
Camera: 500 g (1.1 lb.) |
