Camera
|
|
Image Sensor
|
1/2.8" Progressive Scan CMOS
|
|
Max. Resolution
|
1920 × 1080
|
|
Min. Illumination
|
Color: 0.001 Lux @ (F1.0, AGC ON), B/W: 0 Lux with IR
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed focal lens, 2.8 and 4 mm optional
|
|
Focal Length & FOV
|
4 mm, horizontal FOV 94°, vertical FOV 50°, diagonal FOV 110°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.0
|
|
DORI
|
|
DORI
|
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
Supplement Light Type
|
IR, White Light
|
|
Supplement Light Range
|
Up to 30 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR, VBR
|
|
Region of Interest (ROI)
|
1 fixed region for main stream
|
|
Audio
|
|
Audio Type
|
Mono sound
|
|
Audio Compression
|
G.711 / G.722.1 / G .726 / MP2L2 / PCM / AAC-LC
|
|
Audio Bit Rate
|
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160 Kbps (MP2L2) / 16 to 64 Kbps (AAC-LC)
|
|
Audio Sampling Rate
|
8 kHz/16 kHz
|
|
Environment Noise Filtering
|
Yes
|
|
Network
|
|
Protocols
|
IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP
|
|
Security
|
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
|
|
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Wide Dynamic Range (WDR)
|
Digital WDR
|
|
SNR
|
≥ 52 dB
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Privacy Mask
|
4 programmable polygon privacy masks
|
|
Interface
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
Built-in Microphone
|
Yes, 1 built-in microphone
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
|
|
Linkage
|
Upload to FTP, notify surveillance center, send email, trigger capture
|
|
General
|
|
Power
|
12 VDC ± 25%, 0.45 A, max. 5.4 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6.5 W
|
|
Material
|
Front cover: metal, body: plastic, bracket: plastic
|
|
Dimension
|
67.9 mm × 69.8 mm × 172.9 mm (2.7" × 2.7" × 6.8")
|
|
Package Dimension
|
150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55")
|
|
Weight
|
Approx. 550 g (1.2 lb.)
|
|
With Package Weight
|
Approx. 800 g (1.8 lb.)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Approval
|
|
|
EMC
|
CE-EMC: EN 55032: 2015+A1: 2020, EN 50130-4: 2011+A1:2014, EN IEC 61000-3-2: 2019+A1:2021, EN 61000-3-3: 2013+A1: 2019+A2: 2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
|
|
|
Safety
|
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
|
|
|
Environment
|
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
|
|
Protection
|
IP67: IEC 60529-2013
|
