Product Description
| Code Name | DS-D5024F2-BP2 |
| Display | |
| Screen Size | 23.8 inch |
| Active Display Area | 527.04 (H) mm × 296.46 (V) mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 (H) mm × 0.2745 (V) mm |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H)/178° (V) |
| Color Depth | 16.78 M |
| Contrast Ratio | 1000:1 |
| Response Time | 14 ms |
| Refresh Rate | Typ. 60 Hz, Max. 100 Hz |
| Haze | Haze 25%, 3H |
| Reliability | 7 × 16 H |
| Color Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | Audio Out × 1 |
| Power | |
| Power Supply | DC 12 V, 2.0 A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Environment | |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 20% RH to 90% RH (Non-Condensing) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 10% RH to 90% RH (Non-Condensing) |
| General | |
| VESA | 75 mm × 75 mm (4 – M4 × 6 mm) |
| Bezel Width | 2.0 mm (top/left/right), 23.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 539.7 (W) mm × 399.9 (H) mm × 164.72(D) mm
21.25 (W) inch × 15.74 (H) inch × 6.49 (D) inch
Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm
21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch |
| Package Dimensions (W × H × D) | 652 (W) mm × 445 (H) mm × 116 (D) mm
25.67 (W) inch × 17.52 (H) inch × 4.57 (D) inch |
| Net Weight | 2.32 ± 0.5 kg (5.11 ± 1.10 lb) |
| Gross Weight | 3.74± 0.5 kg (8.25 ± 1.10 lb) |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) ×
1, User manual × 1, Multilingual manual × 1 |
| Remarks | The base is included by default.
The product appearance and parameters in this specification may vary from your
actual device. Please consult our local sales staff for further information |
| Interface | |
| HDMI | HDMI 1.4 digital signal input interface |
| Audio Out | 3.5 mm Audio output interface |
| Interface | |
| VGA | VGA analog signal input interface |
| DC | DC 12 V 2.0 A input interface |
| Warrenty | 3 year |
Hikvision DS-D5024F2-BP2 23.8″ 100Hz FHD IPS Monitor
The Hikvision DS-D5024F2-BP2 23.8″ 100Hz FHD IPS Monitor is a modern, feature-rich display solution designed to deliver smooth performance, vibrant visuals, and long-term reliability for both home and office environments. Built with a 23.8-inch Full HD (1920 × 1080) IPS panel, it provides stunning clarity with excellent color accuracy and wide 178°/178° viewing angles, ensuring that every detail remains clear from any position. The display uses an E-LED backlight and offers a 250 cd/m² brightness level, making it suitable for general work, browsing, entertainment, and light multimedia editing. To enhance visual quality further, the monitor supports 16.78 million colours, a 1000:1 contrast ratio, and 72% NTSC color gamut, allowing images and videos to appear vibrant and lifelike. The 100Hz maximum refresh rate ensures smoother motion compared to standard 60Hz displays, making it ideal for casual gaming, fast-paced videos, and a fluid user experience. With a 14ms response time, this monitor is designed to offer consistent visual performance without major blurring issues. Connectivity is made simple with both HDMI 1.4 and VGA inputs, enabling compatibility with modern PCs, laptops, gaming consoles, and older devices. It also includes a 3.5mm audio out port, allowing users to connect external speakers or headphones when needed. The monitor is powered by a DC 12V/2A adapter, consuming only 24W, making it an energy-efficient choice for daily use. Built for durability, it supports 7×16 hours of reliable operation, suitable for regular professional environments. Its elegant slim-bezel design—just 2mm on the top and sides—makes it perfect for multi-monitor setups. The product also includes a 75×75 mm VESA mount, giving flexibility for wall mounting or monitor arm setups. With a lightweight structure (only 2.32 kg) and sturdy base, it’s easy to install and fits well in compact spaces. Overall, the Hikvision DS-D5024F2-BP2 is a dependable and stylish display solution that blends performance, efficiency, and modern visuals for everyday users.
Buying Guideline of Hikvision DS-D5024F2-BP2 23.8″ 100Hz FHD IPS Monitor
Choosing the right monitor is essential for achieving the best visual experience, whether it’s for work, entertainment, or mixed daily use. The Hikvision DS-D5024F2-BP2 23.8″ 100Hz FHD IPS Monitor offers several modern features, but understanding what to look for will help you make a confident and informed decision.
Key Buying Points
-
Display Size & Resolution
A 23.8-inch screen with Full HD (1920 × 1080) resolution is ideal for desks, providing sharp visuals and a comfortable multitasking space.
-
IPS Panel Quality
The IPS technology ensures vivid colours and wide 178°/178° viewing angles, perfect for productivity, media consumption, and graphics-related tasks.
-
Refresh Rate (100Hz)
A higher refresh rate than standard 60Hz gives smoother motion, great for casual gaming, scrolling, and overall fluid performance.
-
Brightness & Contrast
With 250 cd/m² brightness and 1000:1 contrast ratio, this monitor delivers clear and vibrant images suitable for well-lit rooms.
-
Color Performance
Supporting 16.78 million colors and 72% NTSC gamut, it ensures accurate and rich color reproduction.
-
Response Time (14ms)
Suitable for everyday use, office work, video playback, and general computing.
-
Connectivity Options
HDMI 1.4 and VGA inputs allow compatibility with new and older devices. Audio out lets you connect external speakers or headphones.
-
Power Efficiency
Consumes only ≤24W, making it energy-efficient for long usage periods.
-
Build & Ergonomics
Features slim bezels, a sturdy base, and a VESA (75×75 mm) mount for flexible setup.
To explore more options, you can also check the Hikvision 21.5" DS-D5022F2-2P2 Monitor, which offers a compact and equally powerful display experience. You’ll find both models under the Monitor category, especially within the Hikvision lineup at Tech Valley, allowing you to compare easily and choose the perfect match for your workspace.
